This PU yarn guide wheel is designed for textile machinery to guide and stabilize yarn movement during high-speed operation. The product features a durable polyurethane outer layer combined with a precision metal bearing core, ensuring smooth rotation, low friction, and stable yarn control.
It is widely used as a guiding and tension-support component in various textile processing systems, helping to improve yarn quality and reduce operational wear.
Product Properties
Downloads & Resources
| Resource Type | Link |
|---|---|
| Technical Data Sheet (TDS) | Polyurethane (PU) Material Properties – SU0959 |
Product Details
This PU yarn guide wheel is designed for textile machinery to guide and stabilize yarn movement during high-speed operation. The product features a durable polyurethane outer layer combined with a precision metal bearing core, ensuring smooth rotation, low friction, and stable yarn control.
It is widely used as a guiding and tension-support component in various textile processing systems, helping to improve yarn quality and reduce operational wear.
Key Features
- High-Quality PU Material
The outer wheel is made of wear-resistant polyurethane, providing excellent friction control while protecting yarn from damage.
- Smooth & Stable Rotation
Equipped with a precision bearing core, ensuring low resistance and consistent high-speed performance.
- Lightweight & Durable Structure
Aluminum/metal-reinforced core structure ensures stability and long service life under continuous operation.
- Low Yarn Wear
The smooth PU surface effectively reduces yarn abrasion and improves processing quality.
- Easy Installation
Standardized structure allows easy replacement and compatibility with various textile machines.
Applications
- Textile yarn guiding systems
- Yarn tension control systems
- Winding and processing machinery
- Fiber and filament handling equipment
Material Structure
- Outer Layer: Polyurethane (PU)
- Core: Metal with precision bearing
- Type: Yarn Guide Wheel / Pulley Type
| PU pulley Size Sheet | ||||||||
| Product Number | Outer Diameter of Large End A | Small Flange Outer Diameter B | Groove Diameter C | Bearing Bore D | Slot Width E | Total Thickness F | Bearing Model | R-Groove (Round) / H-Groove (Flat) |
| IN-PU-100-61 | φ100 | φ93 | φ80 | φ12/φ15 | 11 | 15 | 2-6901/2-6802 | R2.5 |
| IN-PU-150-61 | φ150 | φ144 | φ131 | φ20 | 13 | 20 | 2-6804 | R3 |
| IN-PU-200-61 | φ200 | / | φ170 | φ12 | 11 | 20 | 2-6001 | R5 |
| IN-PU-270-61 | φ270 | φ265 | φ255 | φ15/φ20 | 12 | 21 | 2-6002/2-6804 | R4 |
| IN-PU-303-61 | φ303 | φ296 | φ265 | φ20 | 11 | 19 | 2-6804 | R4 |
| IN-PU-325-61 | φ325 | φ319 | φ293 | φ15/φ20 | 12 | 21 | 2-6002/2-6804 | R4 |
| IN-PU-407-61 | φ407 | φ400 | φ363 | φ35 | 16.5 | 26 | 2-6907/2-16006 | R6 |
| IN-PU-510-61 | φ510 | / | φ450 | φ45 | 37 | 44 | 2-6009 | H22 |
| IN-PU-650-61 | φ650 | / | φ600 | φ50/φ55 | 27 | 35 | 2-6010/6-6911 | R9 |
Frequently Asked Questions
The outer layer is made of wear-resistant polyurethane (PU), with a precision metal bearing core.
Yes, it is designed for high-speed operations with smooth rotation and low friction.
The PU surface reduces yarn abrasion, protects yarn from damage, and improves processing quality.
It is compatible with yarn guiding systems, tension control systems, winding machinery, and fiber handling equipment.
It ensures stability, low resistance, and long service life under continuous operation.
Yes, its standardized structure allows simple replacement and compatibility with various machines.
Yes, multiple sizes are available to fit different applications.
Yes, options include R-groove (round) and H-groove (flat) variants depending on the model.
