The Micro Precision Valveless Ceramic Dosing Pump delivers highly accurate fluid dosing with a range from 0 to 300 μL per shot. Designed for laboratory, pharmaceutical, food, and chemical applications, it ensures leak-free performance with corrosion-resistant ceramic construction. This precision liquid dispensing pump offers speeds from 30 to 600 shots per minute, making it ideal for high precision liquid handling in automated systems and research equipment. Featuring a valveless design, it eliminates clogging, providing consistent and reliable dosing for a variety of liquid media
Product Properties
Downloads & Resources
| Resource Type | Link |
|---|---|
| Safety Data Sheet (SDS) | 99% Alumina MSDS-Innovacera |
| Technical Data Sheet (TDS) | 05-99 Alumina Ceramic Material Properties-SU0207 |
Product Details
The milligram-level valveless ceramic liquid injection pump is specifically designed for high-precision micro-volume fluid delivery. Featuring advanced ceramic materials, this pump eliminates the need for valves, ensuring leak-free performance and exceptional durability in harsh environments. Its compact, lightweight design and ceramic sealing technology make it ideal for applications in the pharmaceutical, food, and chemical industries, as well as laboratory and research settings. The valveless ceramic pump guarantees stable, long-term performance, offering precise fluid dosing and reliable operation for demanding fluid-handling processes.
Advantage:
1. Accurate Micro Volume Dispensing
Supports μL-level dosing control for applications that require precise liquid measurement.
2. Excellent Corrosion Resistance Performance
Alumina ceramic components combined with PVDF and PTFE materials provide strong resistance to corrosive liquids.
3. Valveless Structure Design
Ceramic metering pumps, due to their valveless structure, are highly suitable for high-precision liquid dispensing and the transportation of trace amounts of chemical reagents.
4. Easy System Integration
Compatible with PLC control and automation systems used in laboratory or industrial equipment.
5. Flexible Liquid Compatibility
Suitable for various liquid media such as pure water, acidic solutions, and alkaline solutions
Specifications:
| Model |
Dispensing Range |
Dispensing Speed |
Materials |
Accuracy |
|
(μL/shot) |
(shots/min) |
|||
| INBF00 |
0–10 |
30–600 |
PVDF, PTFE, Alumina Ceramic Zirconia Ceramic |
±0.5%
Test medium: Pure water |
| INBF01 |
0–40 |
30–600 |
||
| INBF02 |
20–100 |
30–600 |
||
| INBF03 |
30–180 |
30–600 |
||
| INBF04 |
80–300 |
30–600 |
Customizable inlet and outlet interfaces are available upon request.
Typical Use Cases
• Laboratory liquid dosing and sampling
• Chemical processing and analytical instrumentation
• Pharmaceutical manufacturing and the food industry
• Environmental monitoring systems
• Automated reagent dispensing solutions
Frequently Asked Questions
The pump offers ±0.5% accuracy for pure water, with μL-level dosing control.
The pump uses alumina ceramic, PVDF, and PTFE materials for corrosion resistance.
Yes, the combination of ceramic and fluoropolymer materials provides excellent resistance to corrosive liquids.
Yes, it’s compatible with PLC control and integration into industrial automation systems.
Absolutely, the pump’s precision and corrosion resistance make it ideal for pharmaceutical manufacturing.
Yes, custom inlet and outlet interfaces are available upon request.
The valveless design reduces maintenance needs, but periodic checks for wear are recommended based on usage.
Yes, the pump is suitable for pure water, acidic, and alkaline solutions as specified in the specifications.
